电气性能 Electrical Characteristics

Size and Number of cells		156mm*156mm54pcs(6*9)
Maximum Power(Pmax)	W	200W	205W	210W	215W
Tolerance		3%
Open Circuit Voltage(Voc)	V	33.78	33.39	33.42	33.48
Short Circuit Current(Isc)	A	7.79	8.08	8.27	8.45
Maximum Power Voltage(Vmp)	V	26.85	26.76	26.58	26.88
Maximum Power Current(Imp)	A	7.45	7.66	7.91	7.99
Max.syst.Oper.voltage	V	1000V
Dimension	mm	1476*992*40
Weight	kg	17.2
Operate Temp.scope	℃	-40/+85
Resistances		227 gsteel ball fall down from 1m height and 60m/s wind

（标准测试条件 Standard test condition:AM 1.5, 1000W/m², 25℃）

温度系数 Temperature Coefficients

NOCT	45℃±2℃
短路电流温度系数 Short-circuit current temp coefficient	(0.055±0.01)%k
开路电压温度系数 Open-circuit voltage temp coefficient	-(78±10)mv/k
峰值电流温度系数 Peak power temp coefficient	-(0.48±0.05)%k
输出功率 Power tolerance	±3%

NOCT:Nominal Operating Cell Temperature

特性曲线 Characteristics Curve
