电气性能 Electrical Characteristics

Size and Number of cells		156mm*156mm48pcs(6*8)
Maximum Power(Pmax)	W	160W	170W	180W	190W
Tolerance		3%
Open Circuit Voltage(Voc)	V	29.49	29.47	29.67	29.56
Short Circuit Current(Isc)	A	7.14	7.59	7.98	8.46
Maximum Power Voltage(Vmp)	V	23.72	23.88	23.67	23.95
Maximum Power Current(Imp)	A	6.74	6.98	7.61	7.93
Max.syst.Oper.voltage	V	1000V
Dimension	mm	1318*992*40
Weight	kg	16.4
Operate Temp.scope	℃	-40/+85
Resistances		227 gsteel ball fall down from 1m height and 60m/s wind

（标准测试条件 Standard test condition:AM 1.5, 1000W/m², 25℃）

温度系数 Temperature Coefficients

NOCT	45℃±2℃
短路电流温度系数 Short-circuit current temp coefficient	(0.055±0.01)%k
开路电压温度系数 Open-circuit voltage temp coefficient	-(78±10)mv/k
峰值电流温度系数 Peak power temp coefficient	-(0.48±0.05)%k
输出功率 Power tolerance	±3%

NOCT:Nominal Operating Cell Temperature

特性曲线 Characteristics Curve
